Description
SDRUM is the world’s first intelligent drum machine for guitarists and bassists. By simply scratching across your guitar strings, you teach the SDRUM a kick snare pattern that forms the foundation of the beat you want to hear. Based on this pattern, the SDRUM supplies a professional sounding drum beat with different embellishments and variations to perfectly complement your beat. Gone are the days of having your creative flow disrupted by searching through lists in a frustrating attempt to find the beat you want.
The SDRUM stores up to 36 different songs. Beats are played from a choice of 5 different kits covering a wide range of genres. The pedal also supports three different parts (e.g. verse/chorus/bridge) for each song that can be switched on the fly for enhancing live performances and exploring song ideas.
- SDRUM is the fastest way to go from a beat idea to a working drum track.
- BeatScratch Technology creates drum patterns by strumming your strings
- Studio quality samples and 5 kits for professional sounding drums
- JamSync support works seamlessly with JamMan loopers
TEMPO Button :
- Tap to change the playback tempo. Flashes red and green to indicate beats of a bar. Hold to save a modified tempo.
Part Buttons :
- 3 parts per song each with 3 different intensities for realistic transitions from Verse to Chorus to Bridge.
JamSync Output :
- Easily synchronize with JamSync enabled JamMan looper pedals.
SONG Button :
- Access up to 36 songs by pressing this button and using the HATS/RIDES knob.
AMP OUT :
- Sends only the guitar signal when Mixer outputs are used. When used solely, both drums and guitar are heard and the drum mix is voiced for a guitar amp.
HATS/RIDES Knob :
- Selects 12 different hats/rides styles. Pressing the knob switches between quarter, eighth and sixteenth note timings
GROOVE/KIT Knob :
- Selects between 5 different kits. Also used to set amount of extra embellishments, timing and feel to drum patterns.
GUITAR IN :
- Connect your electric or acoustic guitar or bass here.
MIXER OUTs :
- Provide a full frequency stereo mix of the drums.
FS3X Input :
- Remotely control SDRUM functions with an optional 3 button footswitch.
USB Port :
- Used for product updates.
TEMPO Knob :
- Change the tempo from the stored (center detent) position.
LEARN/PLAY LEDs :
- Shows status of learning a part or playback.
ALT Buttons :
- Select alternate instruments for Hats/Rides (including toms, shakers, tambourines) and alternate Kick and Snare drums.
GUITAR AUDITION Button :
- Turns on or off the drum output when strumming. Hold this button to calibrate your guitar or bass.
KICK/SNARE Pads :
- Audition kits and tap in beats using the KICK and SNARE pads.
Footswitch
- Use to teach a pattern or start song playback. Tapping the switch during playback queues the next part. Holding the switch stops playback.
